Build Package in OpenWrt

Adding and Building Packages/Feeds in OpenWrt

When working with OpenWrt, one of the most common tasks is integrating an external feed into the build tree, then building it into .ipk packages or embedding it directly into firmware. This post summarizes the full workflow based on real-world experience integrating a feed containing several sub-packages (libraries, background services, command-line tools) into an OpenWrt-based SDK tree.

What a feed is, and why “update” + “install” are both needed

In OpenWrt, packages don’t live permanently inside the package/ tree — they’re organized into feeds: collections of packages that can come from a separate Git repo, or from a local directory. The feeds.conf file (or feeds.conf.default) declares these feeds, for example:

src-link my_custom_feed /path/to/sdk/feeds/my_custom_feed

src-link is used for local feeds (a symlink, no network needed), while src-git is used when the feed lives in an external Git repo that needs to be cloned.

Once declared, two steps are always required:

./scripts/feeds update my_custom_feed         # sync the feed's metadata
./scripts/feeds install -a -p my_custom_feed  # symlink packages into the main package tree

The install step is mandatory — without it, make menuconfig won’t show the feed’s packages as selectable options.

Structure of a package Makefile

A minimal OpenWrt package needs to declare its source (PKG_SOURCE_URL), version, and a hash for integrity checking. There are two common patterns:

Tarball style (downloaded directly from a release archive page):

PKG_VERSION:=v1.2.3
PKG_SOURCE:=mylib-v1.2.3.tar.gz
PKG_SOURCE_URL:=https://example.com/mylib/archive/v1.2.3
PKG_HASH:=<sha256 of the tarball>

Direct Git style (used when a package tracks a specific commit rather than a release tag):

PKG_SOURCE_PROTO:=git
PKG_SOURCE_URL:=https://example.com/myproject.git
PKG_SOURCE_VERSION:=<specific commit hash>
PKG_MIRROR_HASH:=<sha256 of the mirror tarball OpenWrt generates>

The key difference for offline builds: the tarball style only requires downloading a single .tar.gz file, while the Git style requires git clone + checking out the exact commit, then manually repackaging it — there’s no ready-made tarball to grab directly.

Building offline: preparing the dl/ directory

When the build machine has no internet access, every source that the Makefiles need must be downloaded in advance on a machine with network access, then copied into the dl/ directory at the root of the SDK tree. OpenWrt checks: if the file already exists in dl/ and its hash matches PKG_HASH/PKG_MIRROR_HASH, it skips the network fetch and uses the local file directly.

The real-world workflow for a multi-package feed typically splits into two groups:

  • Packages downloaded as direct tarballs — just curl/wget the right URL, then verify the SHA256.
  • Packages that require git clone + manual repackaging — clone the repo, check out the exact commit, then compress it into a tarball following OpenWrt’s naming convention (<name>-<version>-<first 8 chars of commit>.tar.gz).

A simple bash script can automate this entire process for both groups of packages.

Important note: for git-based packages you repackage yourself, PKG_MIRROR_HASH is the hash of OpenWrt’s official mirrored copy — it won’t necessarily match the tarball you create yourself. If the build reports a hash mismatch, the safe fix is to update PKG_MIRROR_HASH in the Makefile to the actual hash of the tarball you just created.

Fetching source via the repo tool (when working with an AOSP-style workspace)

Some systems distribute source through Google’s repo tool instead of plain Git — common in large projects with many sub-projects that need to be synced together against a shared manifest. A successfully initialized repo workspace creates a .repo/ structure containing:

  • manifest.xml: declares exactly which project, which path, and which commit/revision needs to be synced
  • project-objects/: a shared Git object store used across projects
  • projects/: where the actual working copies live (once repo sync has run)

An interesting detail: if project-objects/ already contains a complete pack file (because a sync happened at some point), you can check out the source entirely offline using plain git commands, without calling repo sync again:

git --git-dir="<path>/project-objects/.../<project>.git" \
    --work-tree="<destination-path>" \
    checkout <commit-hash> -- .

This is useful when you receive a workspace that’s already been synced (for example, packaged up into a zip file for handoff) but the destination machine has no network access.

An easy-to-miss detail: feed directory structure can change between versions

The same feed, at two different points in time, can have a completely different structure — for example, a package that used to sit at the feed’s root directory might get reorganized into a subdirectory grouped by function (services, tools, libraries, etc.) in a newer version, and new packages may be added along the way.

If you upgrade to a newer feed version without revisiting feeds.conf, build scripts, or make package/<feed>/<path>/compile commands, the build will fail with “package not found” errors even though the source is perfectly valid — simply because the path has changed.

Full workflow summary

  1. Declare the feed in feeds.conf (src-link for local, src-git for remote)
  2. ./scripts/feeds update <feed name>
  3. ./scripts/feeds install -a -p <feed name>
  4. (For offline builds) Pre-download all source referenced by each Makefile’s PKG_SOURCE_URL/PKG_SOURCE_PROTO, and place it in dl/
  5. make menuconfig → select the packages to build
  6. make package/<feed>/<package-path>/compile V=s
  7. Check the output: .ipk files land in bin/targets/.../packages/, or get embedded into the image if building a full firmware

Conclusion

Integrating an external feed into OpenWrt isn’t mechanically difficult (it’s just feeds update + feeds install + build), but two things commonly trip people up: managing source for offline builds (which requires understanding whether a Makefile’s PKG_SOURCE_URL is tarball-style or git-style) and tracking directory structure changes across feed versions over time. Preparing a source-download script in advance, and always double-checking package paths before building, are two habits that help avoid most of the common errors in this workflow.
